Model：WT50-YT(ASY)2600/2800/21000
Its extruder, cylinder and screw rods are made of quality alloy steel, that have been nitrogen treatment and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polyethylene (LDPE), high density polyethylene (HDPE)and linear low density polyethylene(LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
|
Model |
WT50-YT(ASY)2600 |
WT50-YT(ASY)2800 |
WT50-YT(ASY)21000 |
|
Applied Materials |
LDPE.HDPE.LLDPE |
LDPE.HDPE.LLDPE |
LDPE.HDPE.LLDPE |
|
Screw DIA |
50mm |
55m |
65mm |
|
Screw L/D Ratio |
28:1 |
28:1 |
28:1 |
|
Blow Film Motor Power |
11Kw |
15Kw |
18.5Kw |
|
Max Extruded Quantity |
35kg/h |
50Kg/h |
65Kg/h |
|
Film I lead DIA |
φ60,φ 100 |
φ80,φ150 |
φ100,φ200 |
|
Blow Film Width |
600mm |
800mm |
1000mm |
|
Blow Film Thickness |
0.01-0.10mm |
0.01-0.10mm |
0.01-0.10mm |
|
Length Range of Printing |
191-1200mm |
191-1200mm |
191-1200mm |
|
Printing Width |
600mm |
800mm |
1000mm |
|
Total Power |
28Kw |
32Kw |
40kw |
|
Weight of Machinery |
3.5T |
4T |
5T |
|
Dimensions of Machinery |
6000 x 2400 x 4000mm |
6200 x 2600 x 4300mm |
6400 x 2800 x 4800mm |
